Magnification3-12x
Objective44mm
Eye Relief3-4"
Tube Size30mm
FFP — Reticle scales with magnification
Target
Not to scale. Reference only.
Magnification6x
3x5x7x9x12x
Reticle Dimensions
Main hash spacing1 MIL
Sub-hash spacing0.5 MIL
Adjustment per click.1 MIL
Max elevation adjustment45 MIL
Max windage adjustment45 MIL
FOV @ 100 yds (3x)36.7 ft
FOV @ 100 yds (12x)8.8 ft
Features
First Focal Plane (FFP)
Side Focus Parallax Adjustment 8YDS-Infinity
Exposed Target Turrets w/ Return to Zero (RTZ)
6 Reticle Brightness Settings w/ Off Positions
HD Glass w/ Fully Multi-Coated Lens
Barrage Reticle (MIL) Red Illumination
Impact Resistance 800 G Forces
Fog Proof
Waterproof (IPX4)
Operating Temperature -4°F to 140°F
Lifetime Warranty
Specifications
Magnification3-12x
Objective Lens Diameter44mm
Eye Relief3-4"
Field of View @ 100yds36.7-8.8 ft
Tube Size30mm
Adjustment Per Click.1 MIL
Max Elevation Adjustment45 MIL
Max Windage Adjustment45 MIL
Weight27 oz (no mount)
Length9.7"
Material6061-T6 Aircraft Grade Aluminum
