Magnification1–8×
Focal PlaneSFP
Objective24mm
Weight16.4 oz
SFP — Reticle stays fixed at all magnifications
Target
Not to scale. Reference only.
1×2×3×4×5×6×7×8×
Reticle Dimensions
Reticle TypeFiber Wire MOA — SFP
Center Dot.5 MOA illuminated dot
Illumination6 brightness levels with off between
Adj. Per Click.5 MOA
Max Elevation100 MOA
Max Windage100 MOA
Field of View109.2 ft @ 1× — 13.6 ft @ 8×
Eye Relief4 inches
Features
Lifetime Warranty
Second Focal Plane (SFP)
Fiber Wire Reticle (Red dot illumination)
.5 MOA center dot
6 brightness levels with off in between
Fully multi-coated lenses
Low profile capped turrets
Fog Proof (nitrogen purged)
Waterproof & Shock Proof
6061-T6 aircraft grade aluminum
Specifications
Magnification1–8×
Length10.7 inches
Objective Lens24mm
Eye Relief4 inches
Field of View109.2–13.6 ft
Tube Size30mm
Turret StyleLow profile capped
Adj. Per Click.5 MOA
Max Elevation100 MOA
Max Windage100 MOA
Weight16.4 oz (no mount)
Construction6061-T6 aluminum
